What is FCImg?

FCImg is a free PHP chart library that allows you to generate PNG and JPEG images of your charts on the server, without even rendering the chart in a browser. It renders the JavaScript version of FusionCharts at the server and and then internally uses the open-source wkhtmltoimage shell utility to convert the charts to images. See live generation of chart images at FCimg gallery.

FCImg Gallery

The chart images generated by FCImg could be used in the following scenarios:

  • When you need to email dashboards or reports containing FusionCharts
  • When you need to build PDFs of reports or dashboards and embed FusionCharts
  • When you need to render images of charts on devices that do not support both Flash or JavaScript

Setting up FCImg

To get FCImg for your server, choose the right variant from the list below:

The system requirements to run FCImg are:

  • Linux or Windows operating systems. Shared hosts are also supported. safe_mode should not be enabled. (Note that safe_mode is deprecated and disabling it is highly recommended. Most hosts disable safe_mode by default).
  • PHP 5.2 or above.

After downloading the appropriate variant, extract the package to a path on your server that is accessible by your PHP Scripts. You will find that there is only one folder – fcimg. Inside this folder, you will find a /bin sub-folder, fcimg.php and template.txt. Next, you will need to set the right permission for the /bin folder contained within this folder. On Linux systems, the contents of /bin needs to be executable. If you downloaded and extract the files directly on the server, the file permissions are already set. However, if you transferred the files using FTP, then you need to set the permissions manually using this command from the directory where you extracted fcimg:

[cciel lang=”bash”]chmod +x fcimg/bin/*

Using FCImg

Using FCImg is fairly simple. You include the fcimg.php file and invoke fusioncharts_to_image function with a bunch of parameters, as listed and explained below.

require "fcimg/fcimg.php";
fusioncharts_to_image (
	"/var/www/report.png",		// Full path to output image, including name.
	"Column3D.swf",				// SWF Alias of chart. Note: SWF File is NOT required.
								// It's just a pointer to which chart type to render.
	$inputString,				// The input XML data string for the chart
	400, 500,					// Height and width of the chart
	array(						// Additional options for conversion
		'imageType' => 'jpg',	// Setting image type as JPG
		'quality' => 75			// Increase output quality
)
);

The fusioncharts_to_image method takes the following arguments, listed in order:

  • outputFilePath: The full path to the output image. If this file already exists, it will be overwritten.
  • swfName: The FusionCharts SWF filename which will be used to determine which type of chart to render.
  • inputString: The Data String in XML or JSON format. Note that the converter will automatically determine whether the input is XML or JSON.
  • height: The height of the chart in pixels.
  • width: The width of the chart in pixels.
  • options: This is an array to configure optional parameters. This is treated as a key-value set.
    • $options["imageType"]: Specifies the type of the image (png/jpg). Default: png.
    • $options["quality"]: The Image quality (0-100). Note that a higher quality might take longer to render. Default: 70.

When you now run this script on your server, you will find the output chart image file [cciel lang=’javascript]report.png under /var/www folder of your server.

What happened behind the scenes?

When this script executed, the following actions happened behind the scenes:

  • FCImg created a HTML file, which included the FusionCharts XT JavaScript files (the evaluation version is stored in template.txt), and the data in XML or JSON. If you opened this file in a regular browser, you would see this chart.
  • It created a virtual Webkit browser and opened the generated HTML file inside that browser.
  • It waited 1500 milliseconds for the animations to complete.
  • It captured the image on this virtual Webkit browser, converted that into image using wkhtmltoimage, and saved it at the path provided.

FCImg takes a couple of seconds to export a single chart on a basic server. This delay is intended because the default animations of FusionCharts take up to 1.5 seconds to complete on certain charts. The fusioncharts_to_image function is a blocking call. It means that the PHP script will not continue until the rendering process is complete (unlike event based callback systems). It is best to call this method in PHP scripts that run on the server directly and do not serve output to browsers e.g., in a script that generates emailed reports, or a script that is executed through a cron-job.

Changing the FusionCharts JavaScript library used in FCImg

By default, FCImg ships with an evaluation copy of FusionCharts JavaScript version, which is not the latest as well. To update to the latest, or even point to your licensed copy of FusionCharts JavaScript graphs , you will need to do the following changes:

  • Remove the contents of template.txt found in the fcimg directory
  • Add all the code from jQuery charts jquery.min.js to template.txt
  • Add all the code from FusionCharts.js to template.txt
  • Add all the code from FusionCharts.HC.js to template.txt
  • Add all the code from FusionCharts.HC.Charts.js to template.txt

Note that the order of files added is important.

Getting on with it

Do give FCImg a spin. It’s useful. It’s free. And if you encounter some painful situations, give a shout to the developer at [email protected]. It will help if you include details like the XML/JSON data.

Take your data visualization to a whole new level

From column to donut and radar to gantt, FusionCharts provides with over 100+ interactive charts & 2,000+ data-driven maps to make your dashboards and reports more insightful

Explore FusionCharts

Leave a comment

Your email address will not be published. Required fields are marked *

This site uses Akismet to reduce spam. Learn how your comment data is processed.

45 responses on “Generate chart images on the server using FusionCharts
